first backloaded horn finished

[angeloitacare]

hi

i finished to build a pair of backloaded horns, using a 8" coaxial driver.Still missing is the front wave guide, and the spikes.
Pictures of how i made them, here at this thread of my forum:

http://www.audiovoice-acoustics.com/forum/showthread.php?t=225

and here the final result, and description, how they sound :

http://www.audiovoice-acoustics.com/forum/showthread.php?t=300

Angelo



[Dev]

Great job Angelo.



[Papa Lazarou]

WOW!
Beautiful!!!



[sandgrownun]

Beautiful speakers, I hope they sounds as good as they look !



[Markus S]

I know BLHs have a lot of friends, but I have never found one where I didn't hear some bass problems due to effects in the changeover between direct and indirect radiation. Personally, I'd rather have a proper bass reflex.



[angeloitacare]

hi Markus

each design has it's flaws. I however am impressed how strong , tight and thunderous bass sounds with this BLH. One thing i think could be made better, is to make a double BLH, with a second horn mouth placed above the driver, to aloud a better dispertion of the bass, like cain & cain does. I will design something like that, and hope to realise soon.

Angelo



[lbr]

That's a beautifully realised design - glad you're enjoying them!



[YNMOAN]

Very nicely done
