My first hi-fi diy job

Discussion in 'DIY Discussion' started by Chris Davies, Jul 6, 2011.

  1. Chris Davies

    Chris Davies

    Joined:
    Jun 16, 2009
    Messages:
    218
    Likes Received:
    1
    My first hi-fi diy job

    Yet to finish it but getting there

    [​IMG]


    It has a michell inverted brass bearing - Michell platter and DC motor - RB250 rewired with silver single run loom - Isokinetik end stub and weight

    I have isolated the arm board from the table with O rings then the arm from the arm board with O rings + O rings on the arm lift and tube to dampen them. The motor housing is filled with sand then damped with 2 O rings.

    Cartridge is a Denon DL 160 phono stage is a Cambridge 640p although i have just bought a Black Cube SE (waiting on delivery)

    Anyone local to me want a listen and cast an opinion give me a shout

    Chris

    Chris Davies, Jul 6, 2011
    #1
  2. Chris Davies

    felix part-time Horta

    Joined:
    Dec 13, 2003
    Messages:
    757
    Likes Received:
    1
    Location:
    dead
    That looks like fun Chris; nice project and different from the norm.

    - oh, and whereabouts are you?

    felix, Jul 6, 2011
    #2
  3. Chris Davies

    Chris Davies

    Joined:
    Jun 16, 2009
    Messages:
    218
    Likes Received:
    1
    Thanks Felix

    Tiss my first diy attempt since school lol

    Essex near frinton on sea

    Chris Davies, Jul 7, 2011
    #3
  4. Chris Davies

    DaveHiFi Seeking Nirvana

    Joined:
    Jan 20, 2006
    Messages:
    126
    Likes Received:
    0
    Location:
    Bradford
    DIY Turntable

    Hi Chris very nice job, would love to have a listen but im up in deepest darkest Yorkshire. I would like to ask if I may, where did you get the motor and bearing from. I am also considering doing a turntable build and any info on procuring good materials would be appreciated.
    Best Regards
    Dave

    DaveHiFi, Jul 7, 2011
    #4
  5. Chris Davies

    Chris Davies

    Joined:
    Jun 16, 2009
    Messages:
    218
    Likes Received:
    1
    Hi Dave

    Thanks :)

    I got the motor and bearing from http://www.analogueseduction.net/ http://www.analogueseduction.net/

    They offer very good service and keep you upto date on orders. I did consider the Ebay standalone motors at 80quid but read some 50/50 reviews so thought at least the michell DC has an upgrade path and is of high quality to start with.

    The plater i got from ebay 80 quid used. Birch ply from ebay from the hobbies shop as its good quality 9mm

    Hope that helps some

    Chris

    Chris Davies, Jul 7, 2011
    #5
  6. Chris Davies

    DaveHiFi Seeking Nirvana

    Joined:
    Jan 20, 2006
    Messages:
    126
    Likes Received:
    0
    Location:
    Bradford
    Hi Chris,

    thanks for the info, I too saw the cheap Ebay stuff and was unsure of the quality and agree that the motor with speed accuracy top trumps a lot of the design aspect.

    Thanks again my friend, PS are you considering doing a review when it 'beds in' ?.

    DaveHiFi, Jul 8, 2011
    #6
  7. Chris Davies

    Chris Davies

    Joined:
    Jun 16, 2009
    Messages:
    218
    Likes Received:
    1
    Hi Dave

    Na i'm not experienced enough to review it but anyone who wants to can :) It sounds good to me a definite improvement over my Pro-ject Xperience deck

    Chris

    Chris Davies, Jul 9, 2011
    #7
